REX-C100 8800W Thermostat + Heatsink + Thermocouple + SSR-80DA, 80DA Solid State Module Intelligent Temperature Control Kit

Thermostat parameters:
1. Voltage: 220V
2. Opening size: 45x45 mm
3. Control method: PID control
4. Input method: K/EPT100 (optional)
5. Output mode: SSR solid state relay
6. Product size: 48x48x110mm

Solid state module parameters:
1. Control method: DC AC control
2. Input voltage: 3-32V DC
3. Ambient temperature: -30 degrees Celsius to +70 degrees Celsius
4. Working frequency: 50-60Hz
5. Control current: 3-35mADC
6. Product size: 45x27x58 mm
7. Product weight: 81g

Screw thermocouple parameters:
1. Model: K type.
2. Screw specification: M6 inch
3. Cable length: 1 meter
4. Measuring range: 0-400 degrees Celsius
5. Wiring terminal: U-shaped terminal.
6. Product weight: 16g

Heatsink Parameters:
1. Material: Aluminum
2. Size: 50x50x82mm
3. Hole distance: 48mm
4. Product weight: 61g
