LINEPAUDIO B895 Five-Channel Stereo Microphone Mixer with Headphone Monitoring
€61,49
Disponibile
Product information 1. The B895 is a five-channel stereo mini mixer designed for audio and video applications with independent volume control and headphone/line output. The product has one XLR input, one 1/8 input and three...
Pagamenti sicuri
Acquista con metodi di pagamento protetti.
Spedizione tracciata
Segui il tuo ordine dopo l’acquisto.
Assistenza clienti
Supporto disponibile per informazioni sul prodotto.
Descrizione prodotto
Product information
1. The B895 is a five-channel stereo mini mixer designed for audio and video applications with independent volume control and headphone/line output. The product has one XLR input, one 1/8 input and three groups of stereo RCA inputs. It has enough gain and output level to connect to power amplifier with RCA or 1/8 jack. 12VDC adapter power supply. Channel 1 has an XLR microphone input with switchable Phantom power. Channel 2 has 1/8 and RCA input. Channel 3 and channel 4 have RCA jacks. The product can also output 1/8 headphone output, can drive up to 600 ohm headphones, with full frequency response.
2. DC PWR used to connect DC12V power supply.
3. OUT: Stereo RCA jack for connecting mixers or amplifiers.
4. CH 4 & CH 3 INPUT: Stereo RCA jack for connecting signal sources such as CD player, recorder, tuner, computer, mobile phone, tablet, etc.
5. CH 2 INPUT: Stereo RCA and a 1/8 jack (parallel) are used to connect signal sources, such as those mentioned in CH 3 and CH 4, or to wireless microphones or musical instruments. CH 1 INPUT: XLR jack used to connect the microphone. A switchable jumper power source marked on the unit. LINE OUT / HEADPHONES: Stereo 1/8 jack for connecting the audio console, amplifier or stereo headphones. CH 1-4 LEVEL: Adjusts the volume of each channel.
Characteristics
1. For mixed XLR microphone input and up to three RCA input signals
2. Input impedance: 10K ohms for jack
3. CH1 Gain: 32dB XLR jack (maximum gain)
4. Phantom power: for microphone XLR CH 1
5. CH2 Gain: 26dB 1/8 inch & RCA
6. CH 3 and CH 4 Gain: each RCA - 26dB
7. Output: 1/8 inch stereo and stereo RCA
8. Signal to noise ratio: >90dB
9. THD: <0.008
10. SMPTE IMD: <0.008
11. Power supply: 12V DC adapter
1. The B895 is a five-channel stereo mini mixer designed for audio and video applications with independent volume control and headphone/line output. The product has one XLR input, one 1/8 input and three groups of stereo RCA inputs. It has enough gain and output level to connect to power amplifier with RCA or 1/8 jack. 12VDC adapter power supply. Channel 1 has an XLR microphone input with switchable Phantom power. Channel 2 has 1/8 and RCA input. Channel 3 and channel 4 have RCA jacks. The product can also output 1/8 headphone output, can drive up to 600 ohm headphones, with full frequency response.
2. DC PWR used to connect DC12V power supply.
3. OUT: Stereo RCA jack for connecting mixers or amplifiers.
4. CH 4 & CH 3 INPUT: Stereo RCA jack for connecting signal sources such as CD player, recorder, tuner, computer, mobile phone, tablet, etc.
5. CH 2 INPUT: Stereo RCA and a 1/8 jack (parallel) are used to connect signal sources, such as those mentioned in CH 3 and CH 4, or to wireless microphones or musical instruments. CH 1 INPUT: XLR jack used to connect the microphone. A switchable jumper power source marked on the unit. LINE OUT / HEADPHONES: Stereo 1/8 jack for connecting the audio console, amplifier or stereo headphones. CH 1-4 LEVEL: Adjusts the volume of each channel.
Characteristics
1. For mixed XLR microphone input and up to three RCA input signals
2. Input impedance: 10K ohms for jack
3. CH1 Gain: 32dB XLR jack (maximum gain)
4. Phantom power: for microphone XLR CH 1
5. CH2 Gain: 26dB 1/8 inch & RCA
6. CH 3 and CH 4 Gain: each RCA - 26dB
7. Output: 1/8 inch stereo and stereo RCA
8. Signal to noise ratio: >90dB
9. THD: <0.008
10. SMPTE IMD: <0.008
11. Power supply: 12V DC adapter
